SENSOR ALIGNMENT If the disc table swings to the left and right just before the disc is chucked, perform the following adjustment.
Cam LEVER (stopper) assembly
Cam
(1)Rotate the cam and adjust to the position shown in the figure.
Bracket (sensor)
Table assembly
(2) Check that the lever (stopper) assembly secures the disc table as shown in the figure.
Disc table
Swing Lever (stopper) assembly
(4)Moving the disc table right and left with a hand after the screw is fixed, the table will move by the play of a disc table. If the LEDs light up alternately, the adjustment will be performed correctly)
Tepering screwdriver
Luminus board PLAY button Bracket (sensor) PAUSE button
Fixed screw
