ADJUSTING PHASE OF SWING GEAR AND GEAR (U/D)
Note: Follow the assembly procedure in the numerical order given.
5 stopper washer (FR) 4 Push fully the shaft of shaft gear and align the hole shape of gear (loading B). 3 Let the swing gear through under the chassis h and engage its dowel g with the groove f of rotary encoder. g 6 screw (PTPWH M2.6)
2 Install the rotary encoder so that its groove f comes to the position shown in the figure.
f h
1 Insert the shaft gear up to the position where its shaft comes out by 5 mm.
