HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH TURNS OFF
Insert a tapering driver into the aperture of the unit bottom, and turn in the direction of arrow (to OUT direction). * To close the disc tray, turn the driver in the reverse direction (to IN direction).
Tray
NOTE FOR MAIN GAER INSTALLATION
5 Stopper washer (5)
4 Install the MAIN GEAR as show in the drawing.
3 Rotate the GEAR (U/D) A to the arrow Adirection.
B 1 Set the mark of ROTARY ENCODER.
2 Slide the SET LEVER to the arrow B direction.
�4�
|
