POSITIONING THE SPEAKERS
Position the speakers to make the most of Dolby, DTS or DSP surround effect. Front speaker (L/R) Centre speaker (C) Position in the centre of the two front speakers. In addition, position on or below the TV set, if connecting a TV set to the unit. Surround speakers (LS/RS) Place the surround speakers directly to the side of or slightly behind the listening area. Align them horizontally, about 1 metre above ear height. Sub woofer (SW) Place the sub woofer in any place near the two front speakers. Before using the unit, be sure to make speaker settings in accordance with your speaker configuration (see page 16).

CONNECTING THE SUPPLIED ANTENNAS 3
Connect the FM antenna to the FM 75� terminal and the AM antenna to the AM LOOP jack. FM antenna AM antenna

A

NT

EN

NA

A

M

LOOP

5�) M 7 IAL F AX (CO

When not connecting the sub woofer
Select the "R,VNEE " mode when the speaker system B is turned off. 1 Press and hold FRONT SPEAKERS A until "EQK@QFD " is displayed. 2 Within 6 seconds, turn MULTI JOG so that "R,VNM " (initial setting) is displayed. 3 Press ENTER. 4 Within 6 seconds, turn MULTI JOG so that "R,VNEE " is displayed, then press ENTER.

To stand the AM loop antenna on a surface
Fix the claw to the slot as shown in the illustration.

To position the antennas
Keep antennas away from metallic objects, electrical equipment (including the unit itself) and cords. FM antenna: Extend fully and position for the best reception. If reception is poor, connect an optional outdoor antenna to the FM 75� terminal. AM antenna: Rotate to find best reception.

En

USING AC OUTLETS ON THE UNIT 2
The unit is equipped with AC outlets. You can use them once the unit is connected to an AC power socket on a wall. Do not connect equipment beyond their capacity (120 W, 1 A MAX. and TOTAL).

ENGLISH

7

PREPARATIONS
