MAC-V700

� Step 3n: Loading the disc into the player
When the [ENT] button is pressed, the disc is loaded into the player.
[ ENT ]

After the disc is transferred from the carriage and loaded into the player, the rightmost dot will disappear from the display. All the dots blink during operation. Moving to step 4n

� Step 4n: Clamping the disc
When the ENT button is pressed, the disc in the player will be clamped.
[ ENT ]

All the dots blink during operation.

After the disc is clamped, the indication "n" on the mode indicator will change to "r."

The change of indications from "n" to "r" means that a series of operation for disc setting has been completed, upon which the unit automatically moves to be ready to start a series of return steps. The steps for returning the disc to its original position in the disc stocker will be executed if the [ESC] button is pressed.

� Step 4r: Unclampling the disc
When the [ESC] button is pressed, the clamper will open.
[ ENT ]

All the dots blink during operation.

Moving to step 3r

� Step 3r: Unloading the disc from the player
When the [ESC] button is pressed, the disc is pulled out of the player and transferred to the carriage.
[ ENT ]

After the disc is unloaded from the player and transferred to the carriage, the rightmost dot will light. All the dots blink during operation. Moving to step 2r
